FGS387YL0 03 – COOKTOP

Products

PositionProduct
1Grate
2Top, Main (Almond)
2Top, Main (White)
3Bracket, Hinge RH
4Bracket, Hinge LH
5Panel, Manifold
6Knob, Control (4)
7Bracket, Mounting (L.H.)
7Bracket, Mounting (R.H.)
8Cap, Burner
9Ring, Trim
10Screw, Burner Mtg.
