FGS387YL0 05 – CONTROL PANEL

FGS387YL0 05 – CONTROL PANEL

Written by

in

FGS387YL0 05 – CONTROL PANEL

Products

Position	Product
1	Panel, Control
2	Clock, Timer
3	Bracket, Timer
4	Cap, End (R.H.)
5	Cap, End (L.H.)
6	Brace, Backguard
7	Retainer, Timer
8	Trim, Wrapper
9	Trim, Vent
10	Trim, Splasher (Almond)
10	Trim, Splasher (White)
11	Shield, Rear Wall
12	Shield, Inner Bkgd
13	Knob, Clock (3)
14	Light, Indicator (2)
15	Lens, Ind Light (3)
16	Light, Indicator
17	Switch, Selector
18	Thermostat
19	Knob, Selector
20	Knob, Thermostat
21	Cable, Anti-Tip
