FGS387YL1 03 – COOKTOP

Products

Position	Product
1	Grate
2	Top, Main (Almond)
2	Top, Main (White)
3	Bracket, Hinge RH
4	Bracket, Hinge LH
5	Panel, Manifold
6	Knob, Control (4)
7	Bracket, Mounting (L.H.)
7	Bracket, Mounting (R.H.)
8	Cap, Burner
9	Ring, Trim
10	Screw, Burner Mtg.
