FH16M3WTFB 02 – CHEST FREEZER PARTS

Products

Position	Product
2	5303925238 Frigidaire Refrigerator Primary Condenser (O/S1)
4	PLUG-DRAIN
6	GROMMET
7	BREAKER-END (2)
8	WCI F300533
9	WCI F300540
19	WCI F128513
28	SCREW HINGE
29	297321900 Frigidaire Refrigerator Hinge Assembly
30	SPACER-HINGE
31	SCREW-HINGE
32	PANEL-LID (WHITE TEXTURE)
33	WCI F129133
38	WCI F118097
39	WCI F128761
40	FASTENER HANDLE (2)
42	297147700 Frigidaire Freezer Plastic Door Key
43	WCI F128024
44	WCI F127470
46	WCI F128897
47	WCI F128163
48	5303212828 Frigidaire Refrigerator Primary Clip
74	HARNESS-W/ PWR CORD
76	216036601 Frigidaire Refrigerator Screw
77	5303212614 Frigidaire Refrigerator Clip
78	WCI F127315
79	CONTROL TEMP
80	5303305677 Frigidaire Replacement Filter Dryer Filters
81	218513300 Frigidaire Refrigerator Compressor Mount Grommet
83	CLIP
84	PANEL
85	KNOB
86	SUPPORT
87	SCREW
88	WCI F300638
89	WCI F300398
90	WCI F300397
93	5303006412 Frigidaire Refrigerator Cover Mounting Strap
95	216858001 Frigidaire Refrigerator Screw
96	WCI F129138
97A	WCI F128777
98A	5304464438 Frigidaire Compressor Run Capacitor
99A	WCI F300579
