FLP310VL5 02 – EXTERNAL OVEN
Written by
in
FLP310VL5 02 – EXTERNAL OVEN
Products
Position
Product
1
Panel, Side (2) (White)
1
Panel, Side (2) (Almond)
2
Frame, Front
3
Rail, Base (2)
4
Screw, 10-12 X 1/2 (4)
4
Base, Front
5
Support, Main (2)
5
Screw, 10-32 X 1/2 (1)
6
Support, Rear (2)
8
SCREW
8
Flue, Box
9
Panel, Rear
10
Burner Box
10
WP308685 Whirlpool Microwave Screw
12
Screw, 10-24 X 3/8 (2)
12
Hinge, Door (2)
13
Seal, Door (2) (Side)
14
Seal, Door (Top)
15
Bumper, Cooktop (2)
20
Shield, Insulation
21
Leg, Leveler (4)
22
Nut (4)
31
Anti Tip Kit
32
Anchor (2)
33
Bracket
34
W11693756 Whirlpool Screw Assembly
35
Locator stud (2)
35
Stud Screw (2)
←
