FMW240EN2D 05 – SHELVES AND SUPPORTS

FMW240EN2D 05 – SHELVES AND SUPPORTS

Written by

in

FMW240EN2D 05 – SHELVES AND SUPPORTS

Products

PositionProduct
1A5304455852 Frigidaire Refrigerator Screw
1CHANNEL-RS & LS
2WCI G171608-08
3WCI G172436-16
4TRIM-SHELF-FRONT (4)
5WCI 3015454
6PAN-STORAGE UPPER
7COVER-PAN UPPER
7AGASKET-COVER UPR (2) (NON-ILLUSTRATED)
9TRIM-PAN LOWER
10PAN-STORAGE LOWER
11COVER-PAN-LOWER
12WCI G171687
12ASCREW-TRIM MTG (2) (NON-ILLUSTRATED)
13WCI 3017909
14HANGER-BASKET RS
15HANGER-BASKET LS
16SHELF, BOTTOM FREEZER
17TRIM (3)
18SHELF
19A5304509705 Frigidaire Refrigerator Grommet
20WCI G174571-01
20ALABEL-SHELF-LOWER (NON-ILLUSTRATED)
21WCI G174556-01
21ALABEL-SHELF-UPPER (NON-ILLUSTRATED)
22TANK-WATER
23WCI G163938
245308010366 Frigidaire Refrigerator P1-Water Inlet Tube
25WCI G166705
26WCI G186058
27WCI G186057
28131420300 Frigidaire Screw
29WCI G163295-02
