FP18TFF2 03 – CABINET PARTS

FP18TFF2 03 – CABINET PARTS

Written by

in

FP18TFF2 03 – CABINET PARTS

Products

PositionProduct
1WCI 08012843
2241710601 Frigidaire Refrigerator Screw
3WCI 08012829
4WCI 08000007
5WCI 08000100
6WCI 08000757
7WCI 08000184
95303001321 Frigidaire Refrigerator Lower Hinge Pin
10WCI 08017609
11SHIM
12WCI 3018914
13WCI 3018915
14WCI 08010006
15WCI 08000806
16SHELF (2)
17WCI 08000071
18WCI 08000055
20WCI 08000066
21WCI 08000067
22WCI 08009820
22A5304455650 Frigidaire Refrigerator Screw
23WCI 08009793
24LABEL, KNOB
25WCI 08010011
26AWCI 08000009
26WCI 3200810
27TUBE
28215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
29AWCI 08009816
29CONTROL BOX
31WCI 08000129
32316538904 Frigidaire Oven Lamp Light
33WCI 08000056
34PIN-PUSH (2)
35WCI 08010012
36RING-SEAL
375308000010 Frigidaire Refrigerator Evaporator Fan Blade
38WCI 08000124
395304455651 Frigidaire Refrigerator Screw
40WCI 08000107
415300158289 Frigidaire Evaporator Fan Motor
42WCI 08000043
43WCI 08000042
44G187559 Frigidaire Refrigerator Bushing
45TUBE
46WCI 08009771
47WCI 08000126
48WCI 08003583
49WCI 08003584
50WASHER-MULLION (4)
51SPACER (NON-ILLUSTRATED)
52WCI 3018916
53WCI 08012258
54WCI 3200369
55WCI 08010008
56WCI 08009772
575309918806 Frigidaire Refrigerator Light Switch Door
58WCI 08000070
59TOP-REFRIGERATOR
60AWCI 08006993
60WCI 08009751
61WCI 08015543
62WCI 08000097
64WCI 08003585
65TAPPING PLATE (2)
66FERRULE
67FERRULE
68WCI 08007128
69WCI 08010017
71WCI 08013636
72WCI 08016571
73PLUG-SHORT TEST HOLE (NON-ILLUSTRATED)
