FP18TLA1 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

FP18TLA1 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

in

FP18TLA1 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
*27426HOT TUBE REPAIR KIT
1WCI G163133
2BRACKET-CONDENSER MOUNTING (4)
3AWCI 08009617
35308000039 Frigidaire Refrigerator Screw
4HARNESS-WIRING, CONTROL/DIVIDER,(NON-ILLUSTRATED)
5HARNESS-COMPRESSOR
6CORD, SERVICE
7WCI 3001197
85304455651 Frigidaire Refrigerator Screw
105303001199 Frigidaire Refrigerator Wiring Harness Clamp
11STRAP-BALE
12WCI 08000728
13240396801 Frigidaire Refrigerator Tube Clamp
145308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
155317842502 Frigidaire Defrost Heater
16INSULATOR
17EVAPORATOR
185303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
19WCI 08013648
20PLUG-EVAPORATOR INSULATION RH
21WCI 08017227
225303305677 Frigidaire Replacement Filter Dryer Filters
23WCI 08013663
24218513300 Frigidaire Refrigerator Compressor Mount Grommet
25WCI 08003633
26CLIP (4)
27DEFROST PAN & NUT
27ADEFROST PAN-ORIGINAL COMPRESSOR
27B5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
28WCI 3001348
29PAN RETAINER KIT-SERVICE
30COMPRESSOR-SERVICE
31RELAY-ORIGINAL
32WCI 3201563
33WCI 08016583
