FP18TMF3 03 – CABINET PARTS

Products

Position	Product
1	WCI 8012843
2	COVER, HNG, COFE
3	WCI 8012829
4	WASHER-1/4 NYLON (3)
5	WASHER-5/16 NYLON
6	SCREWS LEVELING (4)
7	WCI 8003584
8	SCREW-HINGE MOUNTING
9	PIN-LOWER HINGE
10	BRACKET-HNG
11	SHIM-LOWER HINGE
12	WCI 8009828
13	WCI 8009815
14	WCI 8010006
15	WCI 8000806
16	WCI 8000071
17	WCI 8000055
18	WCI 8009921
20	WCI 8000066
21	WCI 8000067
22	WCI 8009820
23	WCI 8009793
24	WCI 8009823
25	WCI 8010011
26A	SCREW-CONTROL MOUNTING (2) (NON-ILLUSTRATED)
26	WCI 8015763
27	WCI 8003637
28	WCI 8000129
29	WCI 8009782
30	WCI 8009922
31	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
32	WCI 8000008
33	WCI 8000056
34	WCI 8013647
35	WCI 8010012
36	WCI 8009755
37	WCI 8000010
38	WCI 8000124
39	WCI 8000098
40	WCI 8000107
41	WCI 8004176
42	WCI 8000043
43	WCI 8000042
44	WCI 8000032
45	WCI 8000004
46	WCI 8009771
47	WCI 8000126
48	WCI 8000127
49	WCI 8000757
50	WCI 8003607
51	WCI 8010007
52	WCI 8000058
54	WCI 8010029
56	WCI 8009772
57	SWITCH, LIGHT
58	SCREW-TOP MOUNTING (3)
59	WCI 8009751
60	WCI 8015543
61	WCI 8010001
62	SWITCH, LIGHT
63	PLUG-REFRIGERATOR LINER (2)
64	WCI 8003585
65	SCREW-HINGE MOUNTING (2)
66	WCI 8006970
67	WCI 8006971
68	BTN., PLUG, COFE
69	TRIM-CRNR-COFE
70	SCREW-BRACKET MOUNTING (4) (NON-ILLUSTRATED)
71	WCI 8000040
72	WCI 8000014
73	WCI 8000082
74	BTN-PLUG (5)
75	WCI 8009759
75A	WCI 8002747
76	PLATE-TAPPING (2)
77	WCI 8000184
