FPCE19TFL1 05 – SHELVES AND SUPPORTS

Products

Position	Product
1	END CAP-SHELF,PROTECTOR
2	TRIM-SHELF-FREEZER
3	TRIM-SHELF-FREEZER
4	SHELF-FREEZER-STEP
5	SCREW (5)
6	WCI 5303211427
7	WCI 8000066
8	WCI 8000067
9	WCI 8009793
10	WCI 8009823
11	WCI 8009817
12	WCI 8009924
13	SCREW-TOP MOUNTING (3)
14	WCI 5308000056
15	WCI 5303001361
16	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
17	RING-FAN ORIFICE
18	WCI 5308000107
19	5300158289 Frigidaire Evaporator Fan Motor
20	WCI 5303001226
21	BRACKET-MOTOR MTG, REAR
22	G187559 Frigidaire Refrigerator Bushing
23	DIVIDER-FOAM
24	NUT, ``U`` TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED)
24	WCI 5308009771
25	WCI 5303001470
26	5309918806 Frigidaire Refrigerator Light Switch Door
27	5303212918 Frigidaire Refrigerator Cont
28	WCI 1121808
29	WCI 8009824
