FPCE19TPH0 02 – DOOR PARTSadmin2025-04-26T08:52:23+00:00FPCE19TPH0 02 – DOOR PARTS
Products
| Position | Product |
|---|
| 1 | GASKET-FRZR DOOR, BROWN, MAGNETIC |
| 2 | 5304455651 Frigidaire Refrigerator Screw |
| 3 | WCI 3018971 |
| 4 | WCI 3018972 |
| 5A | 5303323480 Frigidaire Refrigerator Door Bar End Cap Rh |
| 5 | 5303323481 Frigidaire Refrigerator Left Hand Door Bar End Cap |
| 6 | WCI 5303272525 |
| 7 | BUTTON-WHEAT |
| 8 | BUTTON-WHEAT |
| 9 | HANDLE-DOOR, WHEAT, REFR |
| 13 | WCI 3201581 |
| 14 | BEARING-HINGE |
| 15 | PANEL-FRZR DOOR, WHEAT |
| 16 | SCREW-HANDLE MTG, SPCL CR OVAL HD, 10-24(D) X 5/8, WHEA |
| 17 | 215817806 Frigidaire Refrigerator Egg Tray |
| 18 | GASKET-REFR DOOR, BROWN, MAGNETIC |
| 19 | WCI 3018868 |
| 22B | 5303325991 Frigidaire Refrigerator Door Bar Endcap |
| 22A | 5303325990 Frigidaire Refrigerator Door Bar End Cap |
| 22 | 215516220 Frigidaire Refrigerator Door Rack |
| 23A | INSULATION-BULK (NON-ILLUSTRATED) |
| 23 | WCI 3200310 |
| 24 | PANEL-REFR DOOR, WHEAT |
| 25 | HANDLE-DOOR, WHEAT, REFR |
| 27 | DOOR-DAIRY |
| 28 | 5308000716 Frigidaire Refrigerator Dish |
| 29 | WCI 5303200413 |
| 30 | WCI 5303200414 |
| 31 | WCI 3200570 |
| 31A | SNUGGER-FINGER (NON-ILLUSTRATED) |
| 32 | WCI 5308000255 |
| 33 | DOOR STOP, REFR SECTION |
| 34 | WCI 5308011745 |
