FPCE19TPH0 04 – SHELVES AND SUPPORTS

Products

PositionProduct
*45841WCI 3200589
*45841EXTENSION, AIR DEFLECTOR, WITH INSULATION
1PAN, CRISPER, LH
2TRIM, CRISPER PAN, LH
3WCI 3200571
4TRIM, CRISPER PAN, RH
5SUPPORT, COVER
6WCI 3200572
7WCI 5303272530
8WCI 5303001448
9DEFLECTRO, AIR, W/SEAL
9A5303001449 Frigidaire Refrigerator Seal
10GLASS, MEAT SHELF
10BLOCK-SHELF TRIM, REAR
11TRIM-HALF SHELF
12RETAINER-GLASS, (3) (NON-ILLUSTRATED)
13TRIM-HALF SHELF, MEAT KPR SHELF, REAR
14WCI 530329869
15AWCI 5303001380
15TOP – REFRIGERATOR
16WCI 5303211964
17TRIM-FULL SHELF, SNAP-ON
18WCI 5303211965
20WCI 5303211966
21FRAME-FULL SHELF
21AWCI 5303211962
23WCI 08014528
25WCI 3018891
26215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
27GASKET-CRISPER COVER (NON-ILLUSTRATED)
28AWCI 3200579
28CWCI 5303200580
28WCI 5303018983
28BWCI 5303211968
29316538904 Frigidaire Oven Lamp Light
30KNOB, TEMP CONTROL
315304455649 Frigidaire Refrigerator Screw
32WCI 5303001260
33ATRIM-DELI TRAY
33BHANGER-PAN LH
33CHANGER-PAN RH (NON-ILLUSTRATED)
33WCI 3200584
34WCI 5303018894
35218906802 Frigidaire Light Lamp Socket
36CONTROL BOX
37WCI 5303018896
40CONTROL-DAMPER, MEAT KPR DUCT
41INSULATION-AIR DUCT, UPPER
42WCI 08009767
43WCI 3200588
44WCI 5308016568
45DUCT-MEAT KEEPER, LOWER
46INSULATION-AIR DUCT, LOWER
