FPCE19TPH0 05 – SHELVES AND SUPPORTS

FPCE19TPH0 05 – SHELVES AND SUPPORTS

Written by

in

FPCE19TPH0 05 – SHELVES AND SUPPORTS

Products

PositionProduct
1END CAP-SHELF,PROTECTOR
2TRIM-FRZR SHELF, SMALL
3TRIM-FRZR SHELF, LARGE
4SHELF-FREEZER-STEP
6WCI 5303211427
7DAMPER-FAN COVER
8Nut,push-on
9KNOB, DAMPER
10LABEL, KNOB
11WCI 8009817
11A5304455650 Frigidaire Refrigerator Screw
12WCI 08009924
135304455651 Frigidaire Refrigerator Screw
14WCI 5308000056
15WCI 5303001361
165308000010 Frigidaire Refrigerator Evaporator Fan Blade
17RING-FAN ORIFICE
18WCI 5308000107
195300158289 Frigidaire Evaporator Fan Motor
20WCI 5303205118
21BRACKET-MOTOR MTG, REAR
22G187559 Frigidaire Refrigerator Bushing
23DIVIDER-FOAM
24ANUT, “U“ TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED)
24WCI 5308009771
25WCI 5303001470
265309918806 Frigidaire Refrigerator Light Switch Door
275303212918 Frigidaire Refrigerator Cont
28WCI 01121808
29WCI 08009824
30BUTTON – DECORATIVE PLUG
315303208309 Frigidaire Refrigerator Plug Hole
