FPCE21TFH1 06 – SYSTEM AND AUTOMATIC DEFROST PARTS

FPCE21TFH1 06 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

in

FPCE21TFH1 06 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
15303305677 Frigidaire Replacement Filter Dryer Filters
2WCI 08000094
3WCI 08003600
3AWCI 08009617
4STRAP-BALE
5WCI 08016583
6WCI 08013644
7WCI 08009628
8WCI 08000064
9CLIP (4)
10WCI 08003597
11218513300 Frigidaire Refrigerator Compressor Mount Grommet
12ADEFROST PAN & NUT
12BNUT
12PAN-DEFROST
13WCI 08017226
14WCI 08950230
15WCI 3202863
16WCI 3202891
17CAPACITOR-RUN
18STRAP-CAPACITOR MTG
19WCI 08013663
20WCI 08017227
21WCI 08013648
22WCI 08013646
235303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
24EVAPORATOR
255308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
26WCI 08000728
275317842502 Frigidaire Defrost Heater
28WCI 08009569
29HARNESS-WIRING, CONTROL/DIVIDER (NOT ILLUSTRATED)
305304455651 Frigidaire Refrigerator Screw
315303001199 Frigidaire Refrigerator Wiring Harness Clamp
32240396801 Frigidaire Refrigerator Tube Clamp
33WCI 08950024
33A5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
33BWCI 09960001
345308000039 Frigidaire Refrigerator Screw
