FPCE22V3FF1 03 – FREEZER DOOR PARTSadmin2025-04-26T08:53:08+00:00FPCE22V3FF1 03 – FREEZER DOOR PARTS
Products
| Position | Product |
|---|
| 1 | WCI 5303001022 |
| 2 | WCI 08009965 |
| 3 | WCI 5303200272 |
| 5 | WCI 5308002802 |
| 6 | BEARING-HINGE |
| 7 | GASKET-FRZR DOOR, MAGNETIC, UPPER |
| 8 | 5304455651 Frigidaire Refrigerator Screw |
| 9 | WCI 3018625 |
| 10 | WCI 3206367 |
| 12A | SUPPORT-DOOR RACK, RH, (6) |
| 12 | SUPPORT-DOOR RACK, LH, (6) |
| 13 | WCI 3200677 |
| 14 | GASKET-FRZR DOOR, MAGNETIC, LOWER |
| 15 | WCI 08009960 |
| 16 | WCI 5315230801 |
| 17 | WCI 5308010239 |
| 19 | END CAP-BOTTOM (2) |
| 20 | SCREW-HANDLE MTG, 8 CR TRUSS HD, 10(D) X 1/2 |
| 21 | WCI 5303001020 |
| 22 | WCI 08017428 |
| 23 | WCI 3018629 |
| 24 | WCI 5308010229 |
| 25 | WCI 08017432 |
| 26 | WCI 3018630 |
| 27 | WCI 5308000790 |
