FPCE22VWFA0 02 – FREEZER DOOR PARTS – Aparts

FPCE22VWFA0 02 – FREEZER DOOR PARTS

Products

Position	Product
1	WCI 8017586
1A	WCI 8002751
2	WCI 3200732
3	WCI 3200272
5	WCI 8012008
6	WCI 3200733
7	WCI 8010301
8	WCI 8015556
9	WCI 8010660
10	WCI 8010295
11	WCI 8010300
12	SCREW (5)
13	WCI 8010659
14A	WCI 8017047
14	COVER-DOOR PNL
15	WCI 8010308
16A	SCREW-PANEL MOUNTING (56)
16	WCI 3200737
17	WCI 3200738
18	WCI 3200543
19	WCI 3200542
19	WCI 8009987
20	WCI 8000790
21	WCI 8000839
22	WCI 8017423
23	END CAP-TOP (2)
24	SCREW-HANDLE MOUNTING (4)
25	END CAP-BOTTOM (2)
26	WCI 8010229
