FPCE24VWPL0 02 – FREEZER DOOR PARTS

FPCE24VWPL0 02 – FREEZER DOOR PARTS

Written by

in

FPCE24VWPL0 02 – FREEZER DOOR PARTS

Products

PositionProduct
*46282INSULATION-BULK (NON-ILLUSTRATED)
1WCI 5303916905
1AWCI 5315230801
2WCI 5303200715
3WCI 5303200272
4WCI 5303001020
5WCI 5303001022
6WCI 5303200717
7WCI 5303001046
8WCI 5308017045
9WCI 5303001048
10WCI 5303017828
125304455650 Frigidaire Refrigerator Screw
13WCI 5303209287
14WCI 5303017830
14ANUT, SELF-THREADING, 1/8
15BUSHING-LOWER HINGE
16WCI 3200762
17WCI 5303206712
18SUPPORT-DOOR RACK, RH, (6)
19SUPPORT-DOOR RACK, LH, (6)
20WCI 5308000790
215304455651 Frigidaire Refrigerator Screw
22WCI 5303273123
24SCREW-HANDLE MTG, CR OVAL HEAD, 10-24(D) X 5/8, ALMOND,
