FPCI19TFL1 02 – DOOR PARTS

FPCI19TFL1 02 – DOOR PARTS

Written by

in

FPCI19TFL1 02 – DOOR PARTS

Products

PositionProduct
*42672WCI 5308000255
*42672WCI 5308011745
*42672DOOR STOP, REFR SECTION
*42672SNUGGER-FINGER (NON-ILLUSTRATED)
1GASKET-FRZR DOOR, BROWN, MAGNETIC
25304455651 Frigidaire Refrigerator Screw
3WCI 3018971
4WCI 3018972
6WCI 3018973
7PLUG-BUTTON, ALMOND, HANDLE/DR STOP
8PLUG-BUTTON, ALMOND, HINGE BRG HOLE
9HANDLE-COMPLETE
11WCI 5308010239
12END CAP-BOTTOM (2)
13NAMEPLATE
14BEARING-HINGE
15WCI 5308009933
16SCREW-HANDLE MTG, 8 CR TRUSS HD, 10(D) X 1/2
17215817806 Frigidaire Refrigerator Egg Tray
18GASKET-REFR DOOR, BROWN, MAGNETIC
19DOOR-DAIRY
20215516220 Frigidaire Refrigerator Door Rack
215303325990 Frigidaire Refrigerator Door Bar End Cap
21A5303325991 Frigidaire Refrigerator Door Bar Endcap
22RACK-REFR DOOR
23A5303323480 Frigidaire Refrigerator Door Bar End Cap Rh
235303323481 Frigidaire Refrigerator Left Hand Door Bar End Cap
24WCI 5308009930
25WCI 3018976
27HANDLE-COMPLETE
28WCI 5308010229
