FPCI19TIFF2 02 – DOOR PARTS

FPCI19TIFF2 02 – DOOR PARTS

Written by

in

FPCI19TIFF2 02 – DOOR PARTS

Products

PositionProduct
*38904WCI 5308011745
1GASKET-FRZR DOOR, BROWN, MAGNETIC
3WCI 3018971
4WCI 3018972
6WCI 3018973
7BUTTON PLUG-COFFEE
8BUTTON PLUG-COFFEE
9HANDLE-COMPLETE
11WCI 08010239
12END CAP-BOTTOM (2)
13NAMEPLATE
14BEARING-HINGE
15WCI 5308010022
16SCREW-HANDLE MTG, 8 CR TRUSS HD, 10(D) X 1/2
17215817806 Frigidaire Refrigerator Egg Tray
18GASKET-REFR DOOR, BROWN, MAGNETIC
19DOOR-DAIRY
20215516220 Frigidaire Refrigerator Door Rack
22RACK-REFR DOOR
23A5303323480 Frigidaire Refrigerator Door Bar End Cap Rh
235303323481 Frigidaire Refrigerator Left Hand Door Bar End Cap
24WCI 5308010020
25A218843801 Frigidaire Refrigerator Screw
25WCI 3018976
26B5303325991 Frigidaire Refrigerator Door Bar Endcap
26A5303325990 Frigidaire Refrigerator Door Bar End Cap
27HANDLE-COMPLETE
28ASNUGGER-FINGER (NON-ILLUSTRATED)
28WCI 5308010229
28BINSULATION-BULK (NON-ILLUSTRATED)
29WCI 5308000255
30DOOR STOP, REFR SECTION
