FPD14TILA1 03 – CABINET PARTS

Products

Position	Product
1	COVER-HINGE-AVOCADO
2A	WASHER, .34 X .62 X .05, NYLON
2	BRACKET-UPPER HINGE
3A	TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
3	SHIM - UPPER HINGE
4A	5304455651 Frigidaire Refrigerator Screw
4B	BOLT-ROLLER MTG, HEX WASHER HEAD, 1/4-28 X 1/2, (2)
4	WCI 5308009773
5	WCI 5308000184
6A	241710601 Frigidaire Refrigerator Screw
6	HINGE - LOWER DOOR
7	5303001321 Frigidaire Refrigerator Lower Hinge Pin
8	SHIM-LOWER HINGE
9	WCI 3018424
10	WCI 01121808
11	WCI 3018425
12	BUTTON - DECORATIVE PLUG
13	SHELF, REFR (2)
14	KNOB, DAMPER
14A	LABEL, KNOB
15	WCI 08009819
16	DAMPER-FAN COVER
16A	Nut,push-on
17	316538904 Frigidaire Oven Lamp Light
18	WCI 08006978
19	TUBE
20	WCI 5308015762
20A	WCI 5303001260
21	SOCKET-LIGHT/LAMP
22	WCI 5308009730
23	WCI 5308016615
24A	5304455649 Frigidaire Refrigerator Screw
24	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
25	WCI 08006988
26	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
27	RING-FAN ORIFICE
28	WCI 5308000107
29	5300158289 Frigidaire Evaporator Fan Motor
30	WCI 5303001226
31	WCI 5303001227
32	G187559 Frigidaire Refrigerator Bushing
33C	5304455650 Frigidaire Refrigerator Screw
33B	NUT-SPEED (2)
33	WCI 3001358
33A	5303208309 Frigidaire Refrigerator Plug Hole
34	TUBE-RUBBER
35	BRACKET-CTR HINGE
35B	WASHER, NO. 10 STEEL, 7/32 X 7/16 OD (NOT ILLUSTRATED)
35A	WCI 5308012258
36A	WCI 3001370
37	WCI 5308003604
38	WCI 5308017408
39	TROUGH-DRAIN
40	5309918806 Frigidaire Refrigerator Light Switch Door
41	COVER - AIR DEFLECTOR
42	DEFLECTOR-AIR
43	WCI 5308000748
44	WCI 5308000759
45A	WCI 5303001380
45	TOP PANEL-REFR, W/ SNAP BUSHING
46	SUPPORT-COIL COVER
47	WCI 08000185
48	WCI 08003616
