FPD17TFA3 03 – CABINET PARTS

Products

Position	Product
*36656	BOLT-ROLLER ADJ, (2) (NON-ILLUSTRATED)
*36657	PLUG, BUTTON, CABINET LINER (NI)
*36657	WCI 5308011326
1	WCI 5303001227
2	5300158289 Frigidaire Evaporator Fan Motor
3	G187559 Frigidaire Refrigerator Bushing
4	WCI 5303001226
5	RING-FAN ORIFICE
6	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
7	DAMPER-FAN COVER
8	FAN COVER
9	WCI 08009822
10	Nut,push-on
11A	LABEL, KNOB
11	KNOB, DAMPER
12	COVER-HINGE-AVOCADO
13	BRACKET-UPPER HINGE
14	WASHER, .34 X .62 X .05, NYLON
15	SHIM - UPPER HINGE
16	WCI 5308000186
17	WCI 5308000184
18	BRACKET-CTR HINGE
19	WCI 5308012258
20	SCREW-LEVELING (4)
21	WCI 5308003584
22	5303001321 Frigidaire Refrigerator Lower Hinge Pin
23	HINGE BRACKET - BOTTOM
24	241710601 Frigidaire Refrigerator Screw
25	SHIM-LOWER HINGE
25A	TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
26	COVER-HOLE, LOWER HINGE
27	WCI 5303210377
28	WCI 5303207353
29A	WCI 5303001361
29	WCI 5308000056
30	TROUGH-DRAIN
31	WCI 5303001286
32	WCI 5303001287
33	TUBE-RUBBER
34	SUPPORT-COIL COVER
35	CORNER
36	WCI 08010091
37	5304455650 Frigidaire Refrigerator Screw
37A	NUT, ``U`` TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED)
38	WCI 5308000107
39A	5303208309 Frigidaire Refrigerator Plug Hole
39	WCI 3001527
40	BUTTON - DECORATIVE PLUG
41	BUTTON-HINGE-AVOCADO
42	WCI 5308009773
42A	BOLT-ROLLER MTG, HEX WASHER HEAD, 1/4-28 X 1/2, (2)
42B	5304455651 Frigidaire Refrigerator Screw
43	WCI 5308009760
44	SUPPORT, BASE (2)
45	WCI 5308009790
