FPD17TFF2 04 – SHELVES AND SUPPORTS

FPD17TFF2 04 – SHELVES AND SUPPORTS

Written by

in

FPD17TFF2 04 – SHELVES AND SUPPORTS

Products

PositionProduct
1DEFLECTRO, AIR, W/SEAL
1BEXTENSION, AIR DEFLECTOR, WITH INSULATION
1A5303001449 Frigidaire Refrigerator Seal
2WCI 5303001448
3TOP PANEL-REFR
3AWCI 5303001380
4AWCI 3018900
4WCI 5303018899
5WCI 5303001537
6WCI 01121808
7218906802 Frigidaire Light Lamp Socket
8316538904 Frigidaire Oven Lamp Light
9WCI 3018891
10215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
115309918806 Frigidaire Refrigerator Light Switch Door
12WCI 5303018894
13CONTROL BOX
14WCI 5303018896
155304455649 Frigidaire Refrigerator Screw
16WCI 5303001260
17KNOB, TEMP CONTROL
18SPACER-MULLION MTG, STEEL
19WASHER, NO. 10 FLAT, 7/32 X 7/16 OD, STEEL (NI)
20WCI 5308012258
21WCI 3916133
22WCI 5308003604
23WCI 5308017408
24PAN-CRISPER RH
25PAN-CRISPER LH
26SUPPORT-CRISPER CVR, ADJUSTABLE
27WCI 5303018892
28WCI 3200651
29WCI 08010287
