FPD19TFA1 02 – DOOR PARTS

FPD19TFA1 02 – DOOR PARTS

Written by

in

FPD19TFA1 02 – DOOR PARTS

Products

PositionProduct
*41232WCI 5308000255
*41232INSULATION-BULK (NON-ILLUSTRATED)
*41232WCI 5308011745
1GASKET-FRZR DOOR, BROWN, MAGNETIC
25304455651 Frigidaire Refrigerator Screw
3WCI 3018971
4WCI 3018972
6WCI 3200466
7BUTTON-AVOCADO
8BUTTON-AVOCADO
9HANDLE-COMPLETE
11WCI 5308010239
12END CAP-BOTTOM (2)
13NAMEPLATE
14BEARING-HINGE
15WCI 5308010021
16SCREW-HANDLE MTG, 8 CR TRUSS HD, 10(D) X 1/2
18GASKET-REFR DOOR, BROWN, MAGNETIC
19WCI 3200467
20215516220 Frigidaire Refrigerator Door Rack
215303325990 Frigidaire Refrigerator Door Bar End Cap
21A5303325991 Frigidaire Refrigerator Door Bar Endcap
22RACK-REFR DOOR
235303323480 Frigidaire Refrigerator Door Bar End Cap Rh
23A5303323481 Frigidaire Refrigerator Left Hand Door Bar End Cap
24WCI 3916033
25WCI 3018976
26DOOR STOP, REFR SECTION
