FPD19VFA1 02 – REFRIGERATOR DOOR PARTS

FPD19VFA1 02 – REFRIGERATOR DOOR PARTS

Written by

in

FPD19VFA1 02 – REFRIGERATOR DOOR PARTS

Products

PositionProduct
*31124INSULATION-BULK (NON-ILLUSTRATED)
1WCI 3018639
2WCI 5303001022
3WCI 5303200272
4AWCI 5303209639
5NAMEPLATE
6WCI 5308010239
7WCI 3018744
8SCREW-HANDLE MTG, 8 CR TRUSS HD, 10(D) X 1/2
9WCI 5308010229
10END CAP-BOTTOM (2)
11WCI 5315230801
12WCI 5308000790
13SCREW-CLOSER MTG
14GASKET-REFR DOOR, MAGNETIC
15BEARING-HINGE
17SUPPORT-DOOR RACK, RH, (6)
18SUPPORT-DOOR RACK, LH, (6)
19RACK-DOOR, WIDE, REFR, (2)
205303323480 Frigidaire Refrigerator Door Bar End Cap Rh
21WCI 3018776
22WCI 3018777
23WCI 3018638
24WCI 3916063
255303323481 Frigidaire Refrigerator Left Hand Door Bar End Cap
26218843801 Frigidaire Refrigerator Screw
