FPD19VFL1 04 – CABINET PARTS

FPD19VFL1 04 – CABINET PARTS

Written by

in

FPD19VFL1 04 – CABINET PARTS

Products

PositionProduct
*31128TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
*31128PLUG, BUTTON, CABINET LINER (NI)
1COVER-UPPER HINGE, ALMOND
2241710601 Frigidaire Refrigerator Screw
3WCI 5308012934
4WCI 5308000186
5SHIM – UPPER HINGE
6WCI 5303001219
7ANUT, “U“ TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED)
7SCREW-CLOSER MTG
7WCI 08000825
8WCI 5303916448
9WCI 5300169100
10WCI 5303001281
10WCI 5303200733
12WCI 5303001233
13WASHER-NYLON,3/16 X 5/8 OD
15WCI 5308017223
16WCI 5303001231
175304455650 Frigidaire Refrigerator Screw
19WASHER, .28 X .62 X .19, NYLON
20SHIM-BTM HINGE (3)
21HINGE-BOTTOM
22SCREW-HINGE MTG (2) (NON-ILLUSTRATED)
23ACLIP-CABLE
235303289051 Frigidaire Refrigerator Light Switch
24WASHER, EXT TOOTH LOCK, NO. 10 (NON-ILLUSTRATED)
25WCI 5303001230
26CLIP-GRILLE
27WCI 5303016726
28WCI 5308000086
29WCI 5303209723
30ROLLER-FRONT (2)
31SCREW-ROLLER MTG,SPCL IND HEX HD, 5/16-18(23) X 7/8
32SCREW-ROLLER ADJ (2) (NON-ILLUSTRATED)
33TUBE-RUBBER
34WCI 5300077210
35WCI 5308000266
36WCI 5308000265
37Nut,push-on
38WCI 5308000853
39WCI 5303001273
40WCI 5308000013
41WCI 5308000738
42WCI 5303001250
43WCI 3001062
44WCI 5303001286
45WCI 5303001287
46SUPPORT-COIL COVER
475303208309 Frigidaire Refrigerator Plug Hole
48PLUG-DECORATIVE, ICE MAKER HOLE
