FPDA14TMW3 02 – DOOR PARTS

FPDA14TMW3 02 – DOOR PARTS

Written by

in

FPDA14TMW3 02 – DOOR PARTS

Products

Position	Product
1	WCI 8016626
2	SCREW-PANEL MOUNTING (56)
3	NUT
6	WCI 8009864
7	PLUG-HANDLE, WHITE
8	PLUG-HINGE, WHITE
9	HANDLE-COMPLETE
10	TRIM-HANDLE (2)
11	END CAP-TOP (2)
12	END CAP-BOTTOM (2)
13	SCREW-HANDLE MOUNTING (4)
14	HINGE BEARING (8)
15	WCI 8009912
16	WCI 8009843
17	WCI 8009915
18	WCI 8016625
19	WCI 8009786
20	WCI 8009663
21A	WCI 8009898
21	WCI 8009896
22	DOOR RACK CUT TO SIZE
23A	WCI 8009807
23	WCI 8009809
