FPDA18TLH0 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
*26954	WCI 3916557
1	5303305677 Frigidaire Replacement Filter Dryer Filters
2	WCI G163133
3	WCI 08003600
4	5303006412 Frigidaire Refrigerator Cover Mounting Strap
6	WCI 08013644
7	WIRING HARNESS-COMPRESSOR
8	WCI 08000064
9	CLIP (4)
10	WCI 08003597
11	218513300 Frigidaire Refrigerator Compressor Mount Grommet
12	PAN-DEFROST
12C	NUT
12A	WCI 08003634
12B	5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
13	216594300 Frigidaire Refrigerator Starter
14	COMPRESSOR W/ ELECTRICALS-SERVICE
17	PAN RETAINER KIT-SERVICE
19	WCI 3206126
20	WCI 08017227
21	WCI 08013648
22	WCI 08013646
23	5303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
24	EVAPORATOR
25	5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
26	WCI 08010274
27	3206453 Frigidaire Refrigerator Defrost Heater 22 1/4" Wide X 4" Deep
28	WCI 08009569
29	WCI 3018900
30	240396801 Frigidaire Refrigerator Tube Clamp
31	5304455651 Frigidaire Refrigerator Screw
32	5303001199 Frigidaire Refrigerator Wiring Harness Clamp
