FPE17TLA0 03 – CABINET PARTS

Products

Position	Product
*25619	WCI 3206135
1	WCI 08012829
2	WCI 3206100
3	COVER – TOP HINGE – AVOCADO
4	WCI 08000007
5	WCI 08000100
6	WCI 08009760
7	WCI 3206237
8	5308000039 Frigidaire Refrigerator Screw
9	WCI 08003583
10	WCI 08009762
11	WCI 08009790
12	WCI 08009761
13	WCI 08011326
14	WCI 08013678
16	5303001321 Frigidaire Refrigerator Lower Hinge Pin
17	SHIM
18	WCI 3206136
19	TUBE-DEFROST DRAIN
20	RING-SEAL
21	HINGE BRACKET CENTER
22	WCI 08012258
23	WCI 3206120
24	WCI 3206122
25	WASHER-MULLION (4)
26	SPACER (NON-ILLUSTRATED)
27	WCI 08003604
28	WCI 08009638
29	WCI 08000097
30	TUBE
31	FERRULE
32	FERRULE
33	WCI 08003584
35	WCI 08007126
36	WCI 08003585
37	241710601 Frigidaire Refrigerator Screw
38	CORNER TRIM-AVOCADO
39	5304500407 Frigidaire Refrigerator Shelf Mounting Grommet
39A	5304509705 Frigidaire Refrigerator Grommet
40	WCI 08010091
41	WCI 08000184
42	TAPPING PLATE (2)
