FPE19TFL1 02 – DOOR PARTS

FPE19TFL1 02 – DOOR PARTS

Written by

in

FPE19TFL1 02 – DOOR PARTS

Products

PositionProduct
*45452INSULATION-BULK (NON-ILLUSTRATED)
*45452SNUGGER-FINGER (NON-ILLUSTRATED)
1GASKET-FRZR DOOR, BROWN, MAGNETIC
25304455651 Frigidaire Refrigerator Screw
3WCI 3018971
4WCI 3018972
55303323480 Frigidaire Refrigerator Door Bar End Cap Rh
5A5303323481 Frigidaire Refrigerator Left Hand Door Bar End Cap
6WCI 3018973
7PLUG-BUTTON, ALMOND, HANDLE/DR STOP
8PLUG-BUTTON, ALMOND, HINGE BRG HOLE
9HANDLE-COMPLETE
11WCI 5308010239
12END CAP-BOTTOM (2)
13WCI 3201581
14BEARING-HINGE
15WCI 5308009933
16SCREW-HANDLE MTG, 8 CR TRUSS HD, 10(D) X 1/2
17215817806 Frigidaire Refrigerator Egg Tray
18GASKET-REFR DOOR, BROWN, MAGNETIC
19WCI 3018868
215303325990 Frigidaire Refrigerator Door Bar End Cap
21A5303325991 Frigidaire Refrigerator Door Bar Endcap
22215516220 Frigidaire Refrigerator Door Rack
23WCI 3200310
24WCI 5308009930
25HANDLE-COMPLETE
26WCI 5308010229
27DOOR-DAIRY
28DOOR STOP, REFR SECTION
28WCI 5308000255
29WCI 5308011745
