FPE19TFL1 04 – SHELVES AND SUPPORTS

Products

Position	Product
*45469	TRIM-SHELF-FREEZER
*45469	WCI 08012329
*45469	TRIM-SHELF-FREEZER
1	PAN, CRISPER, LH
2	TRIM-PAN
3	PAN, CRISPER, RH
4	TRIM-PAN
5	SUPPORT, COVER
6	WCI 3018987
7	WCI 3018986
8	WCI 5303001448
9	DEFLECTRO, AIR, W/SEAL
9A	EXTENSION, AIR DEFLECTOR, WITH INSULATION
10	WCI 3200315
11	TRIM-HALF SHELF (2)
13	WCI 3200317
14	WCI 3200318
15	TOP – REFRIGERATOR
16	WCI 5303200319
16A	RAIL-GLASS SUPT (2) (NON-ILLUSTRATED)
17	WCI 3018980
18	WCI 3200321
19A	TRIM, MEAT SHELF
19	RETAINER-MEAT SHELF
20	WCI 3200326
21	FRAME-FULL SHELF, CANTILEVER, (2)
22	WCI 3200328
23	WCI 08014528
24	HANGER-PAN LH
24A	HANGER-PAN RH (NON-ILLUSTRATED)
25	WCI 3018891
26	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
27	GASKET-CRISPER COVER (NON-ILLUSTRATED)
28A	WCI 3018984
28	WCI 5303018983
28B	WCI 3200389
29	316538904 Frigidaire Oven Lamp Light
30	KNOB, TEMP CONTROL
31	5304455649 Frigidaire Refrigerator Screw
32	WCI 5303001260
33	END CAP-SHELF,PROTECTOR
34	WCI 5303018894
35	218906802 Frigidaire Light Lamp Socket
36	CONTROL BOX
37	WCI 5303018896
38	WCI 3200330
39	WCI 3200331
40	WCI 5308012258
41	WASHER, NO. 10 FLAT, 7/32 X 7/16 OD, STEEL (NI)
42	WCI 5303200370
43	WCI 5303210351
44	SPACER-MULLION MTG, STEEL
45	WCI 5308010008
46	5309918806 Frigidaire Refrigerator Light Switch Door
47A	WCI 5303001380
47B	WCI 3018900
47	DIVIDER-FOAM
48A	3205266 Frigidaire Refrigerator Edge Protector
48	WCI 5303211427
49	WCI 08009824
50	WCI 01121808
50A	5304455651 Frigidaire Refrigerator Screw
51	5303212918 Frigidaire Refrigerator Cont
52	SHELF-FREEZER-STEP
