FPE21TFL3 02 – DOOR PARTS

Products

Position	Product
*42493	INSULATION-BULK (NON-ILLUSTRATED)
1	WCI 5308017483
2	5304455651 Frigidaire Refrigerator Screw
3	WCI 3019030
4	WCI 3017419
5A	WCI 5308017381
5	5303323480 Frigidaire Refrigerator Door Bar End Cap Rh
6	WCI 3018973
7	PLUG-BUTTON, ALMOND, HANDLE/DR STOP
8	PLUG-BUTTON, ALMOND, HINGE BRG HOLE
9	HANDLE-COMPLETE FRZR (W/ TRIM & END CAPS)
10A	WCI 5308000255
10	DOOR STOP, REFR SECTION
11	END CAP-BOTTOM (2)
12	WCI 5308010239
13	WCI 3201581
14	BEARING-HINGE
15	PANEL, FREEZER, ALMD
16	SCREW-HANDLE MTG, 8 CR TRUSS HD, 10(D) X 1/2
17	215817806 Frigidaire Refrigerator Egg Tray
18	GASKET-REFR DOOR, BROWN, MAGNETIC
19	WCI 3018868
21	5303325990 Frigidaire Refrigerator Door Bar End Cap
21A	5303325991 Frigidaire Refrigerator Door Bar Endcap
22A	SNUGGER-FINGER (NON-ILLUSTRATED)
22	215516220 Frigidaire Refrigerator Door Rack
23	WCI 5303200596
24	WCI 5308009930
25	HANDLE-COMPLETE
26	WCI 5308011745
27	DOOR-DAIRY
