FPE22VWCH4 02 – FREEZER DOOR PARTS – Aparts

FPE22VWCH4 02 – FREEZER DOOR PARTS

Products

Position	Product
1A	WCI 8002751
1	WCI 8017104
2	TRIM-FREEZER DOOR
3	WCI 8000743
5	WCI 8012008
6	WCI 8010248
7	WCI 8010301
8	WCI 8015556
9	WCI 8010660
10	WCI 8010295
11	WCI 8010300
12	SCREW (5)
13	WCI 8010659
14	TRIM COVER-DOOR PNL
14A	WCI 8017047
15	WCI 8010308
16	PANEL-INNER DOOR
17	DOOR RACK (5)
18	WCI 8009971
19	WCI 8009970
20	WCI 8000790
21	SCREW-PANEL MOUNTING (56)
22	WCI 8009947
23	END CAP-TOP (2)
24	SCREW-HANDLE MOUNTING (4)
25	END CAP-BOTTOM (2)
26	WCI 8010229
