FPE22VWCL0 05 – FOOD COMPARTMENT DOORS

Products

Position	Product
1	SUPPORT-RACK LS (NON-ILLUSTRATED)
1A	SUPPORT-RACK RS
2	WCI 8009721
3	WCI 8009720
4	WCI 8009664
6	GASKET-REFR
7	WCI 8000743
8	WCI 8012008
9	WCI 8012824
10B	WCI 8009954
11	WCI 8009926
12	END CAP-TOP (2)
13	SCREW-HANDLE MOUNTING (4)
14	WCI 8010229
15	WCI 8009947
16	END CAP-BOTTOM (2)
17	WCI 8002751
18	WCI 6588927
19	WCI 8000790
20	HINGE BEARING (8)
21	WCI 8009949
22	WCI 8000753
22A	WCI 8000754
23	WCI 8002773
24	WCI 8010023
25	RACK-DOOR (3)
26	WCI 8000812
27	EGG TRAY
28	SCREW-PANEL MOUNTING (56)
