FPE24VWDL2 02 – FREEZER DOOR PARTS – Aparts

FPE24VWDL2 02 – FREEZER DOOR PARTS

Products

Position	Product
1	WCI 8017637
1A	WCI 8002751
2	WCI 8012825
3	WCI 8000743
5	WCI 8012008
6	WCI 8010260
7	WCI 8010301
8	WCI 8017045
9	WCI 8010660
10	WCI 8010295
11	WCI 8010300
12	SCREW (5)
13	WCI 8010659
14	WCI 8010304
14A	WCI 8017047
15	WCI 8010308
16	WCI 8010305
17	WCI 8010303
18	WCI 8009971
19	WCI 8009970
20	WCI 8000790
21	SCREW-PANEL MOUNTING (56)
22A	WCI 8015588
22	WCI 8009947
23	END CAP-TOP (2)
24	SCREW-HANDLE MOUNTING (4)
25	END CAP-BOTTOM (2)
26	WCI 8010229
