FPEM18FL0 03 – CABINET PARTS

Products

Position	Product
*24144	WCI 8016571
*24144	PLATE-TAPPING (2)
1	WCI 8006970
2	WCI 8006971
3	WCI 8000004
4B	SCREW-CONTROL MOUNTING (2) (NON-ILLUSTRATED)
4A	HARNESS
4	THERMOSTAT
5	COVER
6	BRACKET-CONTROLS
6A	INSULATOR
7	WELL
8	REFLECTOR
9A	WCI 8003581
9	215846604 Frigidaire Refrigerator Defrost Timer
9B	WCI 8000008
10B	WCI 8002738
10	WCI 8012843
10A	SCREW-HINGE MOUNTING (2)
11	WCI 8012829
12A	SCREW-PANEL MOUNTING (56)
12	WCI 8000042
13	WCI 8000032
14	HOUSING
15	WCI 8000036
16	WCI 8000043
17	WCI 8000010
18	COVER
19	KNOB
20A	WCI 3018745
20B	WCI 3018746
20	SHIELD-LIGHT
21	WCI 8000815
22	WCI 8000801
23	KNOB
24	WCI 8002744
25	DUCT-AIR
26	INSUL-LWR DUCT
27	WCI 3015057
28	DAMPER
28A	NUT
29	TUBE-DRAIN
30	DAMPER
30A	WCI 8002728
31	WCI 8000729
32	WCI 3016726
33	WCI 8000091
34	WCI 8000168
35	WCI 8000059
35B	SCREW-MTG (2) (NON-ILLUSTRATED)
35C	WCI 8000011
35A	WASHER-1/4 NYLON (3)
36	WCI 8000088
36B	WCI 8000001
36A	WCI 8000013
37	PAN
38	COVER, HNG, ALMD
39	WCI 8000067
40	WCI 8000265
41	WCI 8000266
42	WCI 8000118
42A	WCI 8009568
43	WCI 8007129
44	WCI 8000107
45	WCI 3018720
