FPES21TNA1 03 – CABINET PARTSadmin2025-04-26T08:38:22+00:00FPES21TNA1 03 – CABINET PARTS
Products
| Position | Product |
|---|
| *41009 | PLUG, BUTTON, CABINET LINER (NI) |
| *41009 | TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED) |
| 1 | COVER-HINGE-AVOCADO |
| 2 | BRACKET-UPPER HINGE |
| 3 | SHIM - UPPER HINGE |
| 4 | WASHER, .34 X .62 X .05, NYLON |
| 5 | CORNER |
| 6 | WCI 5308000184 |
| 7 | BRACKET-CTR HINGE |
| 8 | WCI 5308012258 |
| 8A | WASHER, NO. 10 FLAT, 7/32 X 7/16 OD, STEEL (NI) |
| 8B | SPACER-MULLION MTG, STEEL |
| 9 | WCI 5308000186 |
| 10 | 5303001321 Frigidaire Refrigerator Lower Hinge Pin |
| 11B | TAPPING PLATE, GUSSET, RH (NOT ILLUSTRATED) |
| 11A | TAPPING PLATE, GUSSET, LH (NOT ILLUSTRATED) |
| 11 | BRACKET-LOWER HINGE, W/ HINGE PIN |
| 12 | 241710601 Frigidaire Refrigerator Screw |
| 13 | WCI 5303212488 |
| 17 | WCI 5303212598 |
| 19 | WCI 5303212490 |
| 22 | WCI 5303212487 |
| 23 | WCI 5308009773 |
| 24 | BOLT-ROLLER MTG, HEX WASHER HEAD, 1/4-28 X 1/2, (2) |
| 26 | WCI 5303210377 |
| 27 | WCI 5303207353 |
| 28 | WCI 5308000056 |
| 29 | WCI 5303001361 |
| 30 | WCI 5303001286 |
| 31 | WCI 5303001287 |
| 32 | TUBE-RUBBER |
| 33 | SUPPORT-COIL COVER |
| 34 | BUTTON-HINGE-AVOCADO |
| 35 | CHANNEL, RH & LH |
| 36 | 5304455852 Frigidaire Refrigerator Screw |
| 38 | WCI 08009825 |
| 39 | WCI 08009937 |
| 41A | LABEL, KNOB |
| 41 | KNOB, DAMPER |
| 42 | Nut,push-on |
| 43 | DAMPER-FAN COVER |
| 44 | 5308000010 Frigidaire Refrigerator Evaporator Fan Blade |
| 45 | RING-FAN ORIFICE |
| 46 | 5304455651 Frigidaire Refrigerator Screw |
| 47 | G187559 Frigidaire Refrigerator Bushing |
| 48 | WCI 5303001226 |
| 49B | 5304455650 Frigidaire Refrigerator Screw |
| 49A | NUT, ``U`` TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED) |
| 49 | COVER, COIL |
| 50 | BUTTON - DECORATIVE PLUG |
| 51 | 5300158289 Frigidaire Evaporator Fan Motor |
| 52 | BRACKET-MOTOR MTG, REAR |
| 53 | WCI 5308000107 |
| 54 | WCI 5303001470 |
