FPI17TFL0 06 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
*15886	WCI 9960001
1	5303305677 Frigidaire Replacement Filter Dryer Filters
2	WCI 8009262
3	BRACKET-CONDENSER MOUNTING (4)
4	WCI 8000117
6	WCI 8013644
7	WCI 8009628
8	WCI 8000064
9	CLIP (4)
10	WASHER (4)
11	WCI 8008778
12	DEFROST PAN-SERVICE COMPRESSOR
13	WCI 8017226
14	WCI 8950233
15	WCI 8017572
16	OVERLOAD CLIP
17	WCI 8017230
18	WCI 8017231
19	WCI 8013663
20	WCI 8017227
21	WCI 8013648
22	WCI 8013646
23	WCI 8000073
24	PANEL, INTERIOR FOOD DOOR
25	WCI 8000110
26	WCI 8010274
27	HEATER-DEFROST
28	WCI 8009638
29	WCI 3018900
30	WCI 8950024
31	SCREW-BRACKET MOUNTING (4) (NON-ILLUSTRATED)
32	WCI 8009617
33	WCI 8003643
34	SCREW-PANEL MOUNTING (56)
35	CLAMP-CABLE (3)
36	WCI 8000187
37	CLAMP-STRAIN RELIEF (3)
