FPI17TPH0 05 – SHELVES AND SUPPORTS

FPI17TPH0 05 – SHELVES AND SUPPORTS

Written by

in

FPI17TPH0 05 – SHELVES AND SUPPORTS

Products

PositionProduct
1END CAP-SHELF,PROTECTOR
3WCI 5303273119
3BRACKET-MTG (4)
4SHELF
55304455650 Frigidaire Refrigerator Screw
65303212918 Frigidaire Refrigerator Cont
7DAMPER-FAN COVER
8Nut,push-on
9KNOB, DAMPER
10LABEL, KNOB
11WCI 08009821
12WCI 08009822
13WCI 01121808
14WCI 5308000056
15WCI 5303001361
165308000010 Frigidaire Refrigerator Evaporator Fan Blade
17RING-FAN ORIFICE
18WCI 5308000107
195300158289 Frigidaire Evaporator Fan Motor
20WCI 5303205118
21BRACKET-MOTOR MTG, REAR
22G187559 Frigidaire Refrigerator Bushing
23WCI 5303018899
24WCI 3001527
25TROUGH-DRAIN
265309918806 Frigidaire Refrigerator Light Switch Door
275304455651 Frigidaire Refrigerator Screw
28WCI 5303001537
305303208309 Frigidaire Refrigerator Plug Hole
31NUT, “U“ TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED)
32BUTTON – DECORATIVE PLUG
