FPK190EN2T 07 – SYSTEM AND AUTOMATIC DEFROST PARTS

FPK190EN2T 07 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

in

FPK190EN2T 07 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
1WCI G188725
1AWCI G189379
2BRACKET-CONDENSER MOUNTING (4)
35308000039 Frigidaire Refrigerator Screw
4WCI 3017362
55303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
6WCI G189609
7WCI G169493
8WCI G190223
9WCI G167363
10WCI G169641
115308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
125303305677 Frigidaire Replacement Filter Dryer Filters
13WCI G188724
14COMPRESSOR WITH ELECTRICALS
15CLIP, COMPRESSOR MOUNTING (4)
16WASHER, COMPRESSOR MOUNTING (4)
17218513300 Frigidaire Refrigerator Compressor Mount Grommet
18WCI G182225-04
19WCI G188727
20RETAINER, OVERLOAD
225303006412 Frigidaire Refrigerator Cover Mounting Strap
23CORD, SERVICE
245304455651 Frigidaire Refrigerator Screw
25B240396801 Frigidaire Refrigerator Tube Clamp
25A5303001199 Frigidaire Refrigerator Wiring Harness Clamp
26WCI G183584
27B5304455650 Frigidaire Refrigerator Screw
27CWCI G162703
27WIRING HARNESS-CONTROL (NON-ILLUSTRATED)
27AWCI 08017046
28WIRING HARNESS-COMPRESSOR & LIGHTS
