FPK190EN3F 03 – REFRIGERATOR DOOR PARTS

Products

Position	Product
*13593	WCI 5308011745
1	PANEL – EXTERIOR – COFFEE
1A	WCI 5315230801
2A	BEARING-HINGE
2	WCI 5303001022
3	NAMEPLATE FRAME
3A	LABEL-NAMEPLATE
3B	TAPE, ADHESIVE, 60“ LG, FOAM, TRIM/NAMEPLATE, DOUBLE FAC
4	INSULATION-BULK (NON-ILLUSTRATED)
5	WCI 5303200272
6	SCREW-CLOSER MTG
7	WCI 5303201811
8	WCI G166897-03
8B	WCI 5303209636
9	WCI 3016231
10	WCI 5303016229
11	SUPPORT – RACK RH (6)
12	SUPPORT – RACK LH (6)
13	WCI 5308000790
14	218843801 Frigidaire Refrigerator Screw
15A	INSERT – HANDLE (NON-ILLUSTRATED)
15B	SPACER-HANDLE (2) (NON-ILLUSTRATED)
15D	ANCHOR – NUT (2) (NON-ILLUSTRATED)
15C	SCREW (6)
15	HANDLE – DOOR
16	HANDLE END-TOP
17	HANDLE, END-BOTTOM
