FPZ17TFA1 05 – SHELVES AND SUPPORTS

FPZ17TFA1 05 – SHELVES AND SUPPORTS

Written by

in

FPZ17TFA1 05 – SHELVES AND SUPPORTS

Products

PositionProduct
1WCI 01121808
25303212918 Frigidaire Refrigerator Cont
3SHELF
4END CAP-SHELF,PROTECTOR
5WCI 3018897
6TRIM-SHELF-FREEZER
7A5304455852 Frigidaire Refrigerator Screw
7WCI 08000302
8FRAME-CANTILEVER (2)
9WCI 3203936
10WCI 3203931
11AWCI 3018884
11WCI 3018883
11BWCI 3203933
12ARAIL-GLASS SUPT (2) (NON-ILLUSTRATED)
12WCI 3018882
13AWCI 3018890
13HANGER-LH (NON-ILLUSTRATED)
14WCI 08014528
15WCI 3018875
16WCI 3017424
17WCI 3018892
17AGASKET-COVER RS (NON-ILLUSTRATED)
18WCI 3018874
19WCI 3018872
20PAN, CRISPER, LH
21TRIM-PAN
