FPZ17TFA3 03 – CABINET PARTS

Products

Position	Product
1	BRACKET-UPPER HINGE
3	COVER-HINGE-AVOCADO
4	SHIM – UPPER HINGE
5	CORNER
6	BUTTON-HINGE-AVOCADO
7	TUBE-RUBBER
8	WCI 5303001286
9	WCI 5303001287
10	WCI 5303207353
11	WCI 5303210377
12	BOLT-ROLLER MTG, HEX WASHER HEAD, 1/4-28 X 1/2, (2)
13	5304455651 Frigidaire Refrigerator Screw
15	BASE-CABINET
16	WCI 5303212490
22	BOLT-ROLLER ADJ, HEX HD, 1/4-28 X 2.750
24	WCI 5303212488
24A	TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
25B	TAPPING PLATE, GUSSET, RH (NOT ILLUSTRATED)
25	BRACKET-LOWER HINGE, W/ HINGE PIN
25A	TAPPING PLATE, GUSSET, LH (NOT ILLUSTRATED)
26	241710601 Frigidaire Refrigerator Screw
28	WASHER, .34 X .62 X .05, NYLON
29	WCI 5308000186
30	BRACKET-CTR HINGE
31	WCI 5308000184
32	WCI 5308012258
33	WASHER, NO. 10 FLAT, 7/32 X 7/16 OD, STEEL (NI)
34	WCI 3916135
35	SPACER-MULLION MTG, STEEL
36	WCI 5308017408
37	WCI 5308003604
38	CHANNEL, RH & LH
39	5304455852 Frigidaire Refrigerator Screw
40	SUPPORT-COIL COVER
41	5304509705 Frigidaire Refrigerator Grommet
42	5304500407 Frigidaire Refrigerator Shelf Mounting Grommet
43	WCI 5308000056
44	WCI 5303001361
45	PLUG, BUTTON, CABINET LINER (NI)
