FPZ17TFA3 04 – SHELVES AND SUPPORTS

Products

PositionProduct
1KNOB, DAMPER
2LABEL, KNOB
3WCI 08009822
4WCI 08009821
5Nut,push-on
6DAMPER-FAN COVER
75308000010 Frigidaire Refrigerator Evaporator Fan Blade
9RING-FAN ORIFICE
10G187559 Frigidaire Refrigerator Bushing
11WCI 5303205118
12WCI 3001527
12ANUT, “U“ TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED)
14BUTTON – DECORATIVE PLUG
155303208309 Frigidaire Refrigerator Plug Hole
165300158289 Frigidaire Evaporator Fan Motor
17BRACKET-MOTOR MTG, REAR
18WCI 5308000107
19TROUGH-DRAIN
20WCI 5303001537
21WCI 5303018899
21AWCI 3018900
21B3205266 Frigidaire Refrigerator Edge Protector
22TOP PANEL-REFR
23WCI 5303001380
245309918806 Frigidaire Refrigerator Light Switch Door
25DEFLECTRO, AIR, W/SEAL
25BEXTENSION, AIR DEFLECTOR, WITH INSULATION
25A5303001449 Frigidaire Refrigerator Seal
26WCI 5303001448
27316538904 Frigidaire Oven Lamp Light
28218906802 Frigidaire Light Lamp Socket
29A5304455650 Frigidaire Refrigerator Screw
29CONTROL BOX
30KNOB, TEMP CONTROL
31WCI 5303018896
32A5304455649 Frigidaire Refrigerator Screw
32215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
33WCI 5303018894
33AWCI 5303001260
34WCI 3018891
355304455651 Frigidaire Refrigerator Screw
