FPZ21TFF2 06 – SYSTEM AND AUTOMATIC DEFROST PARTS

FPZ21TFF2 06 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

in

FPZ21TFF2 06 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
*41089HOT TUBE REPAIR KIT-SERVICE
*410895303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
*410895304455651 Frigidaire Refrigerator Screw
15303305677 Frigidaire Replacement Filter Dryer Filters
2WCI 5300163133
3AWASHER, EXT TOOTH LOCK, NO. 10 (NON-ILLUSTRATED)
3BRACKET-MTG (4)
45303006412 Frigidaire Refrigerator Cover Mounting Strap
6WCI 5303001197
7WIRING HARNESS, COMPRESSOR,
8CORD-ELECTRIC POWER
9CLIP – COMPRESSOR MTG
10WCI 5308068633
11218513300 Frigidaire Refrigerator Compressor Mount Grommet
12WCI 53001847153
13RELAY-TL
14COMPRESSOR W/ ELECTRICALS
15WCI 5308017582
16CAPACITOR
16AWCI 5033001343
18WCI 5308013663
19INSULATION BLOCK, LH
20INSULATION BLOCK, RH
21INSULATION PLUG, RH
225303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
23WCI 5300162506
245308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
25WCI 5308000728
265317842502 Frigidaire Defrost Heater
27INSULATOR-EVAP, PLASTIC
28HARNESS-WIRING, CONTROL/DIVIDER (NOT ILLUSTRATED)
295304455846 Frigidaire Refrigerator Clamp
305308000039 Frigidaire Refrigerator Screw
315303001199 Frigidaire Refrigerator Wiring Harness Clamp
325308000133 Frigidaire Refrigerator Clamp
33PAN RETAINER KIT, SERVICE
