FPZ21TFH3 06 – SYSTEM AND AUTOMATIC DEFROST PARTS

FPZ21TFH3 06 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

in

FPZ21TFH3 06 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
*39561HOT TUBE REPAIR KIT-SERVICE
*395615304455651 Frigidaire Refrigerator Screw
*395615303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
15303305677 Frigidaire Replacement Filter Dryer Filters
2WCI 5300163133
3BRACKET-MTG (4)
3AWASHER, EXT TOOTH LOCK, NO. 10 (NON-ILLUSTRATED)
4WCI 5303211232
5WCI 5303209254
6WCI 5303001197
7WIRING HARNESS, COMPRESSOR,
9CLIP – COMPRESSOR MTG
10WASHER-COMPR MTG
11218513300 Frigidaire Refrigerator Compressor Mount Grommet
12PAN-DEFROST DRAIN, ORIG/SVCE COMPR
12APAN-DEFROST-ORIG COMPRESSOR
13RELAY-TL
14COMPRESSOR W/ ELECTRICALS
15AWCI 3202891
15WCI 3206096
16CAPACITOR
16AWCI 5033001343
18WCI 5308013663
19INSULATION BLOCK, LH
20INSULATION BLOCK, RH
21INSULATION PLUG, RH
225303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
23WCI 5300162506
245308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
25WCI 5308000728
265317842502 Frigidaire Defrost Heater
27INSULATOR-EVAP, PLASTIC
28HARNESS-WIRING, CONTROL/DIVIDER (NOT ILLUSTRATED)
295304455846 Frigidaire Refrigerator Clamp
305308000039 Frigidaire Refrigerator Screw
315303001199 Frigidaire Refrigerator Wiring Harness Clamp
325308000133 Frigidaire Refrigerator Clamp
33PAN RETAINER KIT, SERVICE
