FPZ24VWFA0 05 – SHELVES AND SUPPORTS

FPZ24VWFA0 05 – SHELVES AND SUPPORTS

Written by

in

FPZ24VWFA0 05 – SHELVES AND SUPPORTS

Products

PositionProduct
*38977DIVIDER-ICEMAKER
*38976WCI 3200580
1WCI 08002744
1A5304455852 Frigidaire Refrigerator Screw
2WCI 3200758
2AWCI 3204640
3WCI 3200759
4WCI 3200685
5WCI 3200683
6WCI 3200682
7WCI 08010240
8AWCI 08008250
8CTRIM-CRISPER COVER, UPPER (NON-ILLUSTRATED)
8BWCI 08008251
8WCI 3200662
9WCI 3200690
10AGASKET-COVER UPR (2) (NON-ILLUSTRATED)
10WCI 3200632
11WCI 3200687
12WCI 08001015
13WCI 3200729
14WCI 08000818
15WCI 08000819
16WCI 08001031
17WCI 3200728
18SHELF-FREEZER, (3)
19WCI 08000305
20SHELF-FREEZER, LOWER
20ALABEL-LOWER SHELF (NON-ILLUSTRATED)
21AWCI 08010356
21SHELF-FREEZER, UPPER
22WCI 08950104
23WCI 08010339
245308010366 Frigidaire Refrigerator P1-Water Inlet Tube
25WCI 08000703
26WCI 08015614
27WCI 08015613
28131420300 Frigidaire Screw
29WCI 08010332
30WCI 3200663
31WCI 3200688
32WCI 08009648
33ASUPPORT-COVER LS (NON-ILLUSTRATED)
33WCI 3201640
33B5304509705 Frigidaire Refrigerator Grommet
34WCI 3200544
35WCI 3200689
36SUPPORT-SHELF (2)
37SCREW-SUPPORT (2)
38SUPT-ICE MAKER (2)
39SCREW (2)
40WCI 08010367
41WCI 08014526
42240396801 Frigidaire Refrigerator Tube Clamp
435304455650 Frigidaire Refrigerator Screw
44SCREW-ICE DR SUPT, CR SPCL PAN HD, 8-15(A) X 1-5/8 (NOTILLUSTRATED)
