FRS23KR4AQ1 15 – ICE & WATER DISPENSER

Products

Position	Product
NI	WCI 218976907
NI	218976904 Frigidaire Refrigerator Water Inlet Tube
1	218976901 Frigidaire Refrigerator P1-Water Inlet Tube
4	WCI 241678703
8	WCI 5304421849
10	241688901 Frigidaire Refrigerator Torsion Spring
14	WCI 240323919
15	Light Bulb/Lamp
16	240548901 Frigidaire Refrigerator P-1 Socket
17	241679801 Frigidaire Screw
23	241649003 Frigidaire Refrigerator Drip Tray
24	5304493021 Frigidaire Refrigerator Actuator Kit
30	241688701 Frigidaire Refrigerator Door Seal
30	241688601 Frigidaire Refrigerator Door Insulation
30	241688501 Frigidaire Refrigerator Door Center
30	241688401 Frigidaire Ice Door Bracket
35	241689301 Frigidaire Refrigerator Rotary Damper
36	WCI 5304421824
38	241689106 Frigidaire Refrigerator Micro Switch
38	WCI 5304422345
38	WCI 5304421827
39	241688801 Frigidaire Refrigerator Pin-Hinge
41	241689001 Frigidaire Refrigerator Actuator Spring
43	WCI 215296300
56	241689201 Frigidaire Refrigerator Screw-Micro Switch
87	241688302 Frigidaire Refrigerator Bearing Plate
87	241688301 Frigidaire Refrigerator Bearing Plate
88	WCI 5304421615
90	WCI 5304421831
91	WCI 5304421850
