| *08487 | HOT TUBE REPAIR KIT, SERVICE |
| 1 | SPACER TUBE |
| 1 | WCI 218787700 |
| 2 | WCI 5303289029 |
| 4 | 5303305677 Frigidaire Replacement Filter Dryer Filters |
| 5 | WCI 218671800 |
| 5 | WCI 218463600 |
| 6 | WCI 215633901 |
| 7 | WCI 215459201 |
| 8 | SCREW,HEX HD SER WSHR ,8-18 X 0.375 |
| 8 | WCI 218803400 |
| 13 | WCI 218168602 |
| 14 | 5317842502 Frigidaire Defrost Heater |
| 15 | WCI 5303321220 |
| 16 | 5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap |
| 17 | INSULATOR-EVAP, PLASTIC |
| 18 | WCI 5303292407 |
| 19 | WCI 218631200 |
| 20 | WCI 5303292406 |
| 20 | WCI 5303292405 |
| 21 | 5303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit |
| 22 | WCI 218811100 |
| 23 | 218513300 Frigidaire Refrigerator Compressor Mount Grommet |
| 25 | WCI 218773500 |
| 29 | 5304478809 Frigidaire Refrigerator Compressor Assembly |
| 30 | WCI 216008904 |
| 31 | WCI 5303321892 |
| 32 | 218762900 Frigidaire CLAMP |
| 41 | 5308000039 Frigidaire Refrigerator Screw |
| 43 | 5303001199 Frigidaire Refrigerator Wiring Harness Clamp |
| 43 | 5308000133 Frigidaire Refrigerator Clamp |
| 45 | 5304455651 Frigidaire Refrigerator Screw |
| 45 | WCI 218769200 |
| 45 | 5304455852 Frigidaire Refrigerator Screw |
| 54 | WCI 5303289292 |
| 54 | WCI 5303289027 |
| 54 | WCI 5303289311 |
| 55 | WCI 218764601 |
| 56 | WCI 218769300 |
| 57 | WCI 218247300 |
| 58 | 240555002 Frigidaire Refrigerator Screw #8-32 X 3/8 |
| 59 | SEAL-FOAM,COND FAN SHROUD |
| 59 | WCI 5303289031 |
| 60 | WCI 215501901 |
| 61 | WCI 215004800 |
| 61 | WCI 5303289032 |
| 61 | WCI 215004700 |
