FV13M2WSFC 17 – SYSTEM AND ELECTRICAL PARTS

Products

Position	Product
*11443	COMPR W/ ELECT
1	SPCR-TOPGRID FRONT (2)
1	SPCR-TOP GRID REAR (NON-ILLUSTRATED)
2	WCI F115299
4	216858001 Frigidaire Refrigerator Screw
5	WCI F119270-3
6	WCI F50732
7	WCI F57966
8	TUBE COVER FIRST
9	WCI F117243-8
10	WCI F117243-9
10	WCI F117243-3
11	297001600 Frigidaire Shelf Support
11	SUPT FRONT RH (3)
12	SCREW (5)
13	WCI F95424
14	WCI F116294
15	WCI F115065
16	WCI F59211
17	SLEEVE
18	216498900 Frigidaire Refrigerator Grommet
19	WCI F117958
21	5303006412 Frigidaire Refrigerator Cover Mounting Strap
22	CLIP
23	WCI F117959
24	WCI F117996
25	WCI F126434
26	5304455846 Frigidaire Refrigerator Clamp
27	RETAINER LEAD WIRE
28	CLIP
29	CLIP COMP WIRE
30	5303305677 Frigidaire Replacement Filter Dryer Filters
31	WCI F58148-52
32	WCI F58105
33	WCI F117447
34	5303289051 Frigidaire Refrigerator Light Switch
35	WCI F112321
36	WCI F96850
37	WCI F119997-4
38	SCREW-CLAMP
39	TUBE
40	SHIELD, COLD CONTROL
41	5300083897 Frigidaire Refrigerator Condenser P1 O/S2
42	COLD CONTROL
43	WCI F125347
44	216036601 Frigidaire Refrigerator Screw
45	BRKT
46	SCREW CONTROL
47	WCI F127809
47	WCI F122198
48	SCREW KNOB
49	WCI F125184
50	WCI F116209-3
51	WCI F125197
52	WCI F86523
53	WCI F119996-4
54	WCI F122199
55	SOCKET
56	WCI F92472
57	WCI F116211-3
58	WASHER (3)
