FV16M9WSFC 15 – SYSTEM AND ELECTRICAL PARTS

Products

Position	Product
1	SPCR-TOP GRID REAR (NON-ILLUSTRATED)
1	SPCR-TOPGRID FRONT (2)
2	WCI F126260
3	WCI F119996-4
4	216858001 Frigidaire Refrigerator Screw
5	WCI F119270-3
6	WCI F125197
7	WCI F116209-3
8	297001600 Frigidaire Shelf Support
8	SUPT FRONT RH (3)
9	WCI F95424
11	WCI F116211-3
12	WCI F59211
13	SLEEVE
14	216498900 Frigidaire Refrigerator Grommet
15	WCI F117958
17	5303006412 Frigidaire Refrigerator Cover Mounting Strap
18	CLIP
19	WCI F117959
20	WCI F117996
21	WCI F128549
22	5304455846 Frigidaire Refrigerator Clamp
23	WCI F59872
24	WCI F125184
25	CLIP
26	5303305677 Frigidaire Replacement Filter Dryer Filters
27	WCI F117447
28	SCREW KNOB
29	WCI F112321
31	WCI F119997-4
32	SCREW-CLAMP
33	TUBE
34	SHIELD, COLD CONTROL
35	5300083897 Frigidaire Refrigerator Condenser P1 O/S2
36	WCI F120061
37	WCI F125347
39	BRKT
40	SCREW CONTROL
41	WCI F120058-1
42	216036601 Frigidaire Refrigerator Screw
43	CAP. CLIP (2)
